| MOQ: | 1 단위 |
| 표준 포장: | 수출 표준 |
| 배달 기간: | 25 일 |
| 지불 방법: | t/t |
| Specifications | |
| Dimension | 12400mm*2610mm*1550mm |
| Payload | 50T |
| Tare weight | About 7.5T |
| Box Body Dimension | 12280mm*2300mm*600mm |
| Box Body | Floor steel sheet 2.5mm, side wall steel sheet 1.2mm |
| Twist lock | 12uints |
| Chassis | |
| Main beam | Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. |
| Frame Beam | Top Flange 14mm,width 140mm; Middle Flange 8mm; Bottom Flange 16mm,width 140mm, main beam height 480mm |
| Frame Floor | The Thickness is 3mm pattern |
| Axle | 3 axles, 13Ton Fuwa brand 16ton brake pads |
| Landing Gear | 28T lifting capacity with two speed |
| King Pin | 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension reinforced type |
| Leaf Spring | 90mm(W)*13mm(T)*10 Layer |
| Pneumatic Braking System | Dual line pneumatic brake system,T30 air chamber ,40L air tanks, Emergency relay valve |
| Rim | 9.0-20*12 pcs |
| Tire | 12R22.5*12 pcs |
| Accessories | One standard tool box |
| Spare tire rack | One |
| Electrical system | 24 volt electrical system.7 pin electrical connector. Parking stop, reverse, number plate and indicator lights. rear lights |
| conform to European standard, rear front and side reflectors | |
| Packing and shipping | |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.
One unit.
Absolutely! We can customize trailers according to your specific requirements.
We provide multiple transportation options:
Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.
Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.
With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.
