Main size
Overall length
15000mm

Overall width
2700mm

Overall height
3100mm

Loading capacity
Loading 8 units of cars.
Capacity of 25Tons.

Chassis
Main beam
Material of high strength steel T700.
Height 400mm.
Welded by automatic submerged-processes.

Main cross beam
Material is high strength steel T700.
Welded by automatic submerged-arc processes

Posts
Main posts
Material of high tensile steel T700.
5 pairs of each trailer

Side bars
Material is high strength steel T700.
Multi numbers installed.

Floor
Material
Manganese steel plate floor thickness of 3mm.
Multi holes designed.
Yellow and red painted track.

Landing gear
20T model landing gear, brand Yahua, with static capacity of 50T.
Single speed linked type, operated at one side.

King pin
2 inches size, installed on the kingpin plate.
JOST brand.

Axle
2 sets of 13T model axles.
Axle beam 1840mm.
Axle loading 13000kgs.

Tire
Tire sized 10R22.5, Double Star or Triangle brand.
4 sets of tires assembled with wheel rim per trailer.

Wheel rim
Sized 8.0-20, Zhengxing brand.
4 pcs of wheel rim per trailer.

Hydraulic
Cylinders
5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars.
Youggu brand.

First unit
At the front post, out&back, extend 600mm.

Second unit
At the end post of gooseneck, out&back, extend 600mm.

Third unit
Under the aircraft style plate, to lift single car, out&back, extend 900mm.

Forth unit
At the post in front of tire, out&back, extend 900mm.

Fifth unit
At the end post of trailer, only out, back by the cars' gravity, extend 1600mm.

Suspension
Mechanical steel suspension system, double axles type.
4 sets of leaf springs installed.

Brake sysem
Dual line air drum brake system with T30/30 type double brake chambers on each axle.

Light system
12v/24v light system.
LED lights, including side, rear, turning.

ABS system
ABS system installed, HN or Kemi brand.

Others
Color optional.
One set of standard tools in tool box.
One bag of belts for firming the cars.

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 0

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 1

태그:

low bed semi trailer,

semi lowbed trailer,

low bed tractor trailer

권장 제품

비디오

2 축 28 톤 하락 베드 로보이 트럭 트레일러 중장비 운송용 반트레일러

지금 연락하세요

비디오

3 축 전면 부하 낮은 침대 트레일러

지금 연락하세요

비디오

최대 운반량 120톤 3축 중량 하부부대 반부대 램프와 측면 벽

지금 연락하세요

비디오

3-Axle 13T Car Carrier Semi Trailer with 500mm Main Beam

지금 연락하세요

비디오

로우베드 가격 굴삭기 운송차 로우 베드 트럭 세미 트레일러 유압식 램프 포함 멀티 3 4 5 액슬 40 60 80 120 100톤 판매

지금 연락하세요

비디오

Two, Three, Four Axle Gooseneck Flatbed Semi Truck with Low Deck, Lowboy, Loader, or Low Bed Semi Trailer

지금 연락하세요

비디오

Heavy-duty Customizable 3-Axis 60-120 Tons Foldable Construction Machinery Transportation Low-bed Trailer Trailer Truck

지금 연락하세요

제품 세부 정보

상품

로우베드 세미 트레일러

컨테이너 반트레일러

측벽 세미 트레일러

차량 운반용 반 트레일러

덤프/티핑 반트레일러

밴& 커튼 사이드 반 트레일러

울타리 세미 트레일러

동물 운송용 반류차

탱커 세미 트레일러

농장 트레일러 및 다른 풀 트레일러

하우 덤프 트럭

견인차 머리

특별 트레일러

트레일러 예비 부품

신 에너지 자동차

특수 차량

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS

MOQ:	1 단위
표준 포장:	수출 표준
배달 기간:	25 일
지불 방법:	t/t

자세한 정보

제품 설명

자세한 정보

원래 장소

중국

브랜드 이름

AOTONG

인증

ISO,CCC

보류:

기계 또는 공기 서스펜션

타이어 사양:

12R22.5

메인 빔:

헤비 듀티 I 빔.

친족 핀:

2 ''/3.5 ''볼트 유형

제동 시스템:

더블 에어 챔버, 브레이크 밸브, 45L 에어 탱크; ABS 옵션

전기 같은:

LED 조명, 7 가지 방법, 24V

그림:

폭발 및 깨끗한 녹, 1 프라임 페인팅 코트, 2 개의 마감화 코트

최소 주문 수량:

1 단위

포장 세부 사항:

수출 표준

배달 시간:

25 일

지불 조건:

t/t

강조하다

2-axle car carrier trailer with ABS

lowbed semi trailer 18T-28T capacity

heavy duty car carrier trailer ABS

제품 설명

Main size
Overall length
15000mm

Overall width
2700mm

Overall height
3100mm

Loading capacity
Loading 8 units of cars.
Capacity of 25Tons.

Chassis
Main beam
Material of high strength steel T700.
Height 400mm.
Welded by automatic submerged-processes.

Main cross beam
Material is high strength steel T700.
Welded by automatic submerged-arc processes

Posts
Main posts
Material of high tensile steel T700.
5 pairs of each trailer

Side bars
Material is high strength steel T700.
Multi numbers installed.

Floor
Material
Manganese steel plate floor thickness of 3mm.
Multi holes designed.
Yellow and red painted track.

Landing gear
20T model landing gear, brand Yahua, with static capacity of 50T.
Single speed linked type, operated at one side.

King pin
2 inches size, installed on the kingpin plate.
JOST brand.

Axle
2 sets of 13T model axles.
Axle beam 1840mm.
Axle loading 13000kgs.

Tire
Tire sized 10R22.5, Double Star or Triangle brand.
4 sets of tires assembled with wheel rim per trailer.

Wheel rim
Sized 8.0-20, Zhengxing brand.
4 pcs of wheel rim per trailer.

Hydraulic
Cylinders
5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars.
Youggu brand.

First unit
At the front post, out&back, extend 600mm.

Second unit
At the end post of gooseneck, out&back, extend 600mm.

Third unit
Under the aircraft style plate, to lift single car, out&back, extend 900mm.

Forth unit
At the post in front of tire, out&back, extend 900mm.

Fifth unit
At the end post of trailer, only out, back by the cars' gravity, extend 1600mm.

Suspension
Mechanical steel suspension system, double axles type.
4 sets of leaf springs installed.

Brake sysem
Dual line air drum brake system with T30/30 type double brake chambers on each axle.

Light system
12v/24v light system.
LED lights, including side, rear, turning.

ABS system
ABS system installed, HN or Kemi brand.

Others
Color optional.
One set of standard tools in tool box.
One bag of belts for firming the cars.

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 0

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 1

태그:

Main size	Overall length	15000mm
	Overall width	2700mm
	Overall height	3100mm
	Loading capacity	Loading 8 units of cars. Capacity of 25Tons.
Chassis	Main beam	Material of high strength steel T700. Height 400mm. Welded by automatic submerged-processes.
Chassis	Main cross beam	Material is high strength steel T700. Welded by automatic submerged-arc processes
Posts	Main posts	Material of high tensile steel T700. 5 pairs of each trailer
Posts	Side bars	Material is high strength steel T700. Multi numbers installed.
Floor	Material	Manganese steel plate floor thickness of 3mm. Multi holes designed. Yellow and red painted track.
Landing gear	20T model landing gear, brand Yahua, with static capacity of 50T. Single speed linked type, operated at one side.
King pin	2 inches size, installed on the kingpin plate. JOST brand.
Axle	2 sets of 13T model axles. Axle beam 1840mm. Axle loading 13000kgs.
Tire	Tire sized 10R22.5, Double Star or Triangle brand. 4 sets of tires assembled with wheel rim per trailer.
Wheel rim	Sized 8.0-20, Zhengxing brand. 4 pcs of wheel rim per trailer.
Hydraulic Cylinders	5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars. Youggu brand.
	First unit	At the front post, out&back, extend 600mm.
	Second unit	At the end post of gooseneck, out&back, extend 600mm.
	Third unit	Under the aircraft style plate, to lift single car, out&back, extend 900mm.
	Forth unit	At the post in front of tire, out&back, extend 900mm.
	Fifth unit	At the end post of trailer, only out, back by the cars' gravity, extend 1600mm.
Suspension	Mechanical steel suspension system, double axles type. 4 sets of leaf springs installed.
Brake sysem	Dual line air drum brake system with T30/30 type double brake chambers on each axle.
Light system	12v/24v light system. LED lights, including side, rear, turning.
ABS system	ABS system installed, HN or Kemi brand.
Others	Color optional. One set of standard tools in tool box. One bag of belts for firming the cars.
